Roger Technology B70/1THP Anweisungen Und Hinweise Für Den Installateur Seite 7

Limitatore di tensione B72/CL - Voltage limiter B72/CL
FC1
Scheda carica batteria B71/BCHP - B71/BCHP battery charger
FC1
SEC2 SEC1
BATTERY CHARGER
SEC2 SEC1
B71/BCHP - HW02 *
(*) SOLO PER
HIGH SPEED E REVERSIBILE
ONLY FOR HIGH SPEED
AND REVERSIBLE
SOLO PER
HIGH SPEED E REVERSIBILE
ONLY FOR HIGH SPEED
AND REVERSIBLE
vedere capitolo / see chapter 18
RED
F3
BLACK
FUSE
T10A
5x20
AGM Battery ONLY
2 x 12V 4,5Ah
2a
2b
7
