Overview
1
2
3
4
5
6
7
8
9
Note: The illustration may vary depending on the dosing head.
EN 6
xxx
xxxxxxxxx
xxxxxxxxxxx
xxxxxxxxxxxx
xxx xxxxxxxx xxxxxxxx
xxxxxxxx xxxxxx
xxxxxxxx xxx
xxxxxxxx xxxx
xxxx
10
11
1 Drive motor
2
Motor nameplate
3 Motor terminal box
4 Vent plug (gear)
5 Drive unit
6 Stroke length adjustment knob
7 Liquid end with relief valve
8 Pump nameplate
9 Fixing holes
10 Relief valve (optional)
11 Diaphragm rupture sensor
Refer to the operating in-
structions for more detailed
information on the other
available versions.
