Phonitor x – Quickstart
DIP switches
By using the DIP switches on the bottom of the unit the following settings can
29
be chosen:
DIP switch 1: ON = The headphone output is boosted by +22 dB.
DIP switch 2: ON = The headphone output is boosted by +12 dB.
If both DIP switches 1 and 2 are ON, a boost of +24 dB is applied.
DIP switch 3: ON = The VU meter is attenuated by 10 dB. VU 0 = +10 dBu.
DIP switch 4: ON = The chosen input passes without volume control directly to
the XLR output (Slave Thru).
DIP switch 5: ON = The chosen input passes without volume control directly to the
RCA output (Slave Thru).
DIP switch 6: ON = Units which are connected to AMP CTL are set to standby to
save power when the output selection is set to
Factory settings
8
Headphone.
29
DIP Switches
