Phonitor x – Quickstart
Start up
1
Read the security advices on page 9!
2
Make sure that the selected mains voltage of the Phonitor x is according to the
mains voltage of your region.
Make sure that the mains switch on the rear of the Phonitor x is set to Off
3
(Off = O / On = I).
4
The standby switch on the front panel has to be set to
5
Connect the supplied power cord to the Phonitor x and an appropriate mains
socket outlet.
If the supplied power cord does not match your mains socket outlet, please contact your dealer.
6
Turn off all devices you wish to connect to the Phonitor x.
Connect the outputs of your analog sources (e.g. CD Player, Phonos) to the
7
analog inputs of the Phonitor x. Please use appropriate audio cables (XLR, RCA).
Audio cables not included in the scope of delivery.
If the DA converter option is fitted connect the outputs of your digital sources
8
(e.g. Mac, PC or CD Player) to the digital inputs of the Phonitor x. Please use
appropiate audio cables (USB, coaxial, optical).
Digital audio cables not included in the scope of delivery.
For Windows
®
installed. Macs, iPhones and iPads do not require a driver since the USB port is Apple-Class compliant.
Connect audio cables (XLR, RCA) between the Phonitor x and a following
9
amplifier or active speakers.
Audio cables not included in the scope of delivery.
Connect your headphone to the balanced or standard headphone output of the
10
Phonitor x.
To protect the headphone power amplifier stage and guarantee a long and consistent performance please note:
• Turn down VOLUME before swapping headphones.
• Never insert a mono jack plug into the front panel stereo jack.
• Make sure that the headphones stereo jack is fully inserted.
• If you use an adapter from 3,5 mm to 1/4" (6,35 mm) on your headphone make sure that the adapter is fully
screwed on respectively fully plugged in.
If you own an SPL Performer power amplifier you can connect the AMP CTL
11
output of the Phonitor x with a mini jack cable to the AMP CTL of the
Performer to switch both units between standby and operation together.
Mini jack cable not included in the scope of delivery.
CAUTION: Do not use this setting to turn an SPL Performer s800 power amplifier on or off, when its serial
number is lower than : Black 00273, Silver 00104, Red 00130
2
is equal to or higher than: Black 0000?, Silver 0000?, Red 0000?
computers download the latest driver from phonitorx.spl.info under the "Driver" tab and have it
.
– and the serial number of the Phonitor x
