To access to the current status parameter display, with the unit in
standby, press the UP/DOWN keys simultaneously for 3 seconds, paying
particular attention to simultaneity.
Use the UP/DOWN keys to scroll to the desired parameter and use the
MODE key to view the current parameter value.
Do not change parameters D2 and D3 as they are
reserved for basic firmware programming by the
manufacturer.
It is possible to detect certain malfunction conditions recognised by the
unit's electronic components, by means of error codes shown below.
In the event of multiple malfunctions, the error codes will be shown in
sequence on the display.
Code
E1
Fan inlet air temperature sensor
E2
Circuit inlet water temperature sensor
E3
11. Remote management with Smart Life app
The unit, equipped with WiFi connectivity, can be managed remotely with
the Smart Life app, which can be downloaded from the main platforms.
Proceed as follows.
1. Search for the Smart Life app from the selected store or scan the
following QR code to access the website. Download and install the
app.
Android
2. Log into the app and, if you do not already have an account, create one
by following the instructions below:
2.1
Click on SIGN UP, then AGREE.
2.2
Enter telephone number or e-mail address.
2.3
Click on GET VERIFICATION CODE and then enter the code
that was sent to validate the account.
2.4
Set your password and click on DONE.
Cod. 1910000000085 - nv02
Possible cause
Fan motor
iOS
3. If you already have an account, please proceed as follows:
3.1 Click on LOG IN and enter your account name and password.
4. Connect to the app in WiFi default mode (Method 1) following the
steps below:
4.1 Connect your mobile device to the available WiFi network.
4.2 Enter the app and click on "+" or ADD DEVICE.
4.3 Select the LARGE HOME folder and click on SMART HEAT PUMP
(WIFI).
4.4 Select the same WiFi network to which the mobile device is
connected and enter its password. Click on NEXT.
4.5 Reset the unit and press
flashes quickly: the unit is trying to synchronise. If this happens,
click on CONFIRM THE INDICATOR IS BLINKING and then on
BLINK QUICKLY.
4.6 The app will show that the unit has been added successfully. Click
on DONE to end the procedure.
- 23 -
English
+
for a long time. The WiFi icon
