1 .2 Manufacturer liability
The manufacturer declines any liability for damages to persons and
property caused by:
•
use of the appliance other than intended
•
non-observance of the user manual instructions
•
tampering with even just one part of the appliance
•
use of non-original spare parts.
1 .3 Disposal
At the end of its working life, this appliance must be delivered
to the special collection facilities for recycling, since it is not
a standard domestic waste. In case of replacement, it can be
delivered to your distributor. This management of the end of
the life of a product allows us to preserve our environment
and to limit the use of natural resources. This symbol, applied on the
product, indicates the obligation to deliver the product at the end of its
working life to a special collection facility, in compliance with Directive
2002/95/EC.
2 . General information
The user instructions as per this booklet refer to Cordivari Design fan
coils, in particular to models:
Height
Width
[mm]
[mm]
VNT2000 DESIGN RUN / SEVEN LINES
593
715
VNT4000 DESIGN RUN / SEVEN LINES
593
925
VNT6000 DESIGN RUN / SEVEN LINES
593
1135
The products presented and described in this manual are equipped with
on-board control devices that enable their full use. In guaranteeing the
full functionality of the machine in question, these control devices act
with priority over IoT control modes (e.g. use of Apps). It is, however,
possible to manage products from Smart devices via the Apps mentioned
in this manual. Signing and agreeing to the terms and conditions of use
of the App - including the processing of personal data - are exclusively
to be understood as an existing relationship between the User and
the Company owning the App. Cordivari S.r.l., in the latter case, is to
be considered an external and extraneous party to the aforementioned
relationship.
Cod. 1910000000085 - nv02
Depth
Net weight
[mm]
[kg]
136
17
136
21
136
25
- 17 -
3 . Technical Features
Air Volume LOW features
Sound power level [dB(A)]
(1)
Electrical power input [W]
Air Volume MEDIUM features
Sound power level [dB(A)]
(1)
Electrical power input [W]
Air Volume HIGH features
Sound power level [dB(A)]
(1)
Electrical power input [W]
Air flow rate [m
/ h]
3
HEATING performance
(Water IN 45 / OUT 40 °C, Air 20°C, Air wet bulb 15°C)
HEATING power [W]
(2)
Water flow rate [l / h]
(2)
Pressure drop [kPa]
(2)
COOLING performance
(Water IN 7 / OUT 12 °C, Air 27°C, Air wet bulb 19°C)
Total COOLING power [W]
(2)
COOLING sensible power [W]
Water flow rate [l / min]
(2)
Pressure drop [kPa]
(2)
Sound power measured according to EN 16583 + EN ISO 3741
(1)
Heating and cooling capacity measured according to EN 1397
(2)
•
Supply voltage 230 V AC 50 Hz
•
Electrical specifications: Class I, IPX0
•
Fuse type: T5A 250V
•
Power cable with Schuko plug L > 1000 mm
•
Bypass solenoid valve management (optional)
•
WiFi connectivity
•
Ambient operating temperature from 5°C to 32°C – 60% RH
•
Water flow temperature from 6°C to 75°C
•
Operating pressure from 1 Bar to 10 Bar
•
Painted aluminium alloy casing
•
Top cover made of high-strength V0 plastic
•
Finned heat exchanger with hydrophilic coating, high heat exchange
efficiency and G1/2" connections
•
Brushless motor DC310V 8P 13W 1400 rpm Class E
•
Condensate collection tray with natural drainage complete with anti-
drip insulation
•
Polypropylene mesh filters
4 . User information
To clean the fan coil painted metal casing, use only a non-abrasive cloth
soaked in water. Never use detergents or aggressive substances. Avoid
any other base or acid solution, chemical, industrial or other substances,
aggressive or corrosive substances (bleach, ammonia, baking soda,
etc.). Use a dry cloth for cleaning the plastic parts (top cover, control
panel and user interface). Do not use abrasive cloths or sponges.
In the absence of motorised water shut-off valves and under operating
conditions characterised by high relative humidity and low water
English
VNT2000
VNT4000
VNT6000
41
41
5
6
46
46
7
9
50
50
10
15
130
250
720
1196
122
205
1.1
3.3
(2)
42
7
47
11
51
16
370
1738
297
7.5
