Start-up
• Wingenroth (Wiroflex)
• R.B.M
• Tiemme
• Jaga
• Siemens
• Idmar
The device can also be installed on
type Danfoss RA
adapter" on page 31)
using the enclosed adapter.
6.2.1 Removing a thermostat
In case of visible damage to the
existing thermostat, valve or heat-
ing pipes, please consult a spe-
cialist.
Remove the old thermostatic head
from your radiator valve:
• Rotate the thermostatic head an-
ticlockwise to the maximum value
(1). The thermostatic head then no
longer presses against the valve
spindle, making it easier to remove.
Figure 5
The thermostatic head may be held in
place in various ways:
• Union nut: Unscrew the union nut
in an anticlockwise direction (2).
The thermostatic head can then be
removed (3).
(see „6.2.4 Danfoss RA
radiator valves
2
1
3
• Snap-on fastenings: Thermostatic
heads that are fastened this way
can be detached by turning the
fastener/union nut anticlockwise
a little. The thermostatic head can
then be removed.
• Compression fittings: The ther-
mostatic head is held in place by a
mounting ring, which is held to-
gether with a screw. Loosen this
screw and remove the thermostatic
head from the valve.
• Threaded connection with set
screw: Loosen the set screw and
remove the thermostatic head.
6.2.2 Mounting the radiator
thermostat
After removing the old thermostatic
head, you can mount the new radiator
thermostat on the heating valve:
• Place the radiator thermostat with
the metal nut (A) on the heating
valve.
If required, you can use one of the
supplied adapters for Danfoss
valves,
(see „6.2.4 Danfoss RA
adapter" on page
supplied support ring.
31), or the
