Endress+Hauser Promag 55S Einbauanleitung Seite 4

EA00069D
1 Overview of conversion kits
The conversion instructions apply to the following conversion kits:
Procedure
Conversion of Promag 55S
compact
to Promag 55S remote
2 Transmitters that can be used for the conversion
Transmitters required for the conversion must be ordered separately. Only transmitters
with the following order codes can be used:
1 2
Order code 5 5
Transmitter
Promag
3 Personnel authorized to carry out conversion
Authorization to carry out a conversion depends on the measuring device' s approval type. The
table below shows the authorized group of people in each case.
Measuring device approval
Without approval
With approval (e.g. IECEx)
For custody transfer
1) 1 = Qualified specialist on customer side, 2 = Service technician authorized by Endress+Hauser,
3 = Endress+Hauser (return measuring device to manufacturer)
4 = Check with local approval center if installation/modification must be performed under supervision.
4
Order code for
conversion kit
DK5UP-6
3 4 5 6 7 8
X X X – X X
Device component (contents)
1 × connection housing, pre-assembled
including connection board and connection plate
1 × conversion kit, cable entry Promag
Connection housing NPT ½"
1 × conversion kit, cable entry Promag
Connection housing G ½"
1 × conversion kit, cable entry Promag
Connection housing M20 × 1.5
1 × sign for transmitter
1 × form for archiving of data
1 × conversion instructions
9 10 11 12
X X X A, R
Personnel authorized to carry out conversion
13 14 15 16
C, S, R * * *
2, 3
2, 3
4
Endress+Hauser
17 18
* *
1)
