7 Preparatory steps: backing up device data
Saving transmitter parameters to the T-DAT using the "T-DAT SAVE/LOAD" function.
Description of Device Functions or Operating Instructions, "Commissioning" section →
data backup with "T-DAT save/load. After modifying the device, insert the T-DAT into
the transmitter.
7.1 Overview of the Histo-ROM and F-CHIP data storage media
Data storage Color
medium
S-DAT Blue
T-DAT Black
F-CHIP (optional) Red
7.2 Applicable documentation
The new documentation supplied with the new transmitter is valid.
8 Conversion of Promag 55 compact version to
Promag 55 remote version
8.1 Removing the aluminum transmitter housing
CAUTION
L
The measuring device is energized!
Risk of fatal injury from electric shock.
‣
Open the measuring device only when the device is deenergized.
8
Promag 55 compact version to Promag 55 remote version
Reinstallation
Reinstallation
Reinstallation
