15 Commissioning softwareFWL-PushPull-45, FWL-PushPull-45 RC
2. Set teaching mode to On. The sub-menu
shown above appears. Parameters 2 to 4
serve to teach-in or teach-out the sensors and
radio switch. Parameters 5 to 7 serve to teach-
in or teach-out the FWL-PushPull RLS-LTRC
on the FWL-PushPull-45 RC master unit.
Before selection of step 5 "FWL-PushPull-45
RC teach-in", it is necessary to define
theFWL-PushPull-45 RC units amongst them-
selves as master-slave.
FWL-PushPull-45 RC units only function in
pairs and only with master-slave assignment.
Parameters
Deactivate teaching-in
Manual EEP input
Change name
Teach-out units
Radio components which can be learned-in
You can teach-in up to 8 connected EnOcean
components. FWL-PushPull-45 radio compon-
ents must support the EEP protocol. Radio com-
ponents with the same EEP can be combined
with the FWL-PushPull-45 system.
Radio components
which can be learned-
in
EasySens radio switch,
4-channel wall transmit-
ter
Humidity/temperature
sensor
CO2/temperature
sensor
7100902 | 03.22
Set value
→ Following table
bathroom, living room
etc.
All released EnOcean
components are un-
learned
EEP
F6-02-01
A5-04-01
A5-09-08
Radio components
which can be learned-
in
VOC/temperature
sensor*
* No EnOcean VOC sensor currently available.
Complete commissioning/maintenance
To save a commissioning or maintenance pro-
tocol. This includes project data, information re-
garding the planner, installer and customers as
well as notes. The unit date, all settings and a
fault logbook are automatically stored. A print file
is generated so that you can save or print it.
Input/read out data set
To read out or input the device configurations.
This can, for example, be sent to the manufacture
in case servicing is needed. Externally created
configuration data can be input.
EEP
A5-09-05
