15 Commissioning softwareFWL-PushPull-45, FWL-PushPull-45 RC
Parameters
Luminosity of LED in-
dicator
Luminosity of LED
standby
Automatic operation
LED standby
Number of FWL-Push-
Pull-45 units
Quantity of FWL-Push-
Pull-30 (TwinUnit)
FWL-PushPull-30
(TwinUnit)
operating mode
FWL-PushPull-30
(TwinUnit)
sensor function
FWL-PushPull-30
(TwinUnit)
button function
FWL-PushPull-30
(TwinUnit)
start delay button
FWL-PushPull-30
(TwinUnit)
duration button function
No. of power units
7100902 | 03.22
Set value
2, 3, 4, 5
0, 1, 2
0 ... 3 ... 6 minutes
1 FWL-PushPull-45
unit pair
2 FWL-PushPull-45
unit pairs
3 FWL-PushPull-45
unit pairs
3 FWL-PushPull-45
units, operation with
odd number of units
5 FWL-PushPull-45
units, operation with
odd number of units
No FWL-PushPull-30
(TwinUnit)
1 FWL-PushPull-30
(TwinUnit)
2 FWL-PushPull-30
(TwinUnit)
3 FWL-PushPull-30
(TwinUnit)
Automatic operation
system operation
Exhaust air mode
intensive ventilation
Exhaust air mode
intermittent ventilation
0 ... 120 sec.
5 ... 10 ... 90 min.
No further LTs/RLS
1 LT/RLS
2 LTs
3 LTs
Slave no. 1
Slave no. 2
Slave no. 3
Parameters
FWL-PushPull RLS-K
function 230 VAC input
Supply air function for
exhaust air fan overrun
time
Modbus communication deactivated
Modbus baud rate
Modbus address
Restore factory settings Keep settings
If the RS-485 interface is configured as a
Modbus interface, no further components
(sensors, power units, room air controls etc.)
can be connected at this interface.
Ventilation
Parameters
Filter service life, unit
filter
Filter change, unit filter:
Acknowledgement
Duration of ventilation
level 5 (intermittent
ventilation)
Duration of night time
level 0 (sleep mode)
Ventilation level Off*
Set value
Sleep function
intermittent ventilation
safety function
supply air function for
exhaust air fan
No overrun time
6 min. overrun time
15 min. overrun time
activated
9600 baud
19200 baud
10 ... 50
restore factory settings
Set value
1 ... 6 ... 8 months
changed, not changed
5 ... 30 ... 90 minutes
15 ... 60 ... 120 minutes
Off blocked, Off pos-
sible
