Mechanical data

Enclosure
Fixing
Shock and vibration
Ambient temperature
Storage temperature
Maximum relative humidity
Altitude
Connection
Mass CSMS-M... Connector version
CSMS-M... Cable version
CSMS-S...
Degree of protection
Protection class according to EN IEC 61558
Degree of contamination
Safety data (according to EN ISO 13849-1) no more
than an ambient temperature of 50 °C on average
up to PL
Category
Service life
PFH module 1
PFH cascaded modules
2 ... n
SIL
Coding according to
DIN EN 14119

Regulations

EN 60947-1, EN 60947-5-2, EN 61326-3-1
EN ISO 13849-1 ; EN 61508, EN 60947-5-3, EN ISO 13849-2
EN 60204-1, EN 61131-2 ETSI EN 300330-1,
ETSI EN 300330-2, EN 62061

EC-conformity

! ATTENTION !
This is a class A product.
In a household environment, this device can cause
Radio Interference - the user must take appropriate
steps where necessary.
e
4
20 years
2.05 • 10 -9 1/h
1.70 • 10 -9 1/h per module
3 (acc. to EN 62061:2005)
High (more than
1000 different codings)
Macromelt, red / PA 6, black
2 through holes Ø 4.5 (for M4 screws)
according to EN IEC 60947-5-2
–25°C – +70°C
–25°C – +70°C
90 % at 40 °C without condensation
≤ 2000 m NHN
Connector M12 male
60 g
185 g
27 g
IP 67
III
3 (in case of metallic contamination, an impairment
of the sensing distances can occur)
This device complies with part 15 of the FCC Rules and
Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by
the party responsible for compliance could void the user's
authority to operate the equipment.

Approvals

TÜV Nord, cCSAus

Maintenance / Service

Contamination by metal-based materials must be removed.
If not, the switch distance will be reduced.
Do not use alcoholic cleaning agents.
The CSMS is maintenance-free.
For long-term and trouble-free operation, please
periodically check the following points:
● solid fit of all components
● reliable switching function
● if damage occurs, please exchange the relevant
components
CSMS-R/RRS: 0800000756, 0235-14 / Status: 2 / Issue date: 2014-08-05
