Approach possibilities

Approach direction
A1
Fig. 6
A2
Fig. 7

Sensing distances

The standard approach direction is shown in figure A1. In this case, the sensing distance of the CSMS unit is typically 13 mm.
The safe switch-off distance (S
ar
The hysteresis is 0,5 mm.
In the transmission area, there are so-called side lobes (see fig. 11), in which the switch is also activated.
For an application with the approach direction A4, the minimum distance between CSMS and actuator must be X ≥ 5 in order to
ensure that an activation in the side lobes is excluded.
Rated sensing distance
Assured sensing distance – On
Hysteresis
Assured sensing distance – Off
24
Approach
direction
illustration
) is 19 mm. At this distance, it is ensured that the sensor switches off the safety outputs.
Fig. 10
A3
Fig. 8
S
A4
s ≥ 5 mm
Fig. 9
min.
S
n
S 10 mm
ao
H
S
ar
O set S
S
typ. max.
13 mm
0.5 mm
19 mm
V
