Large screws, hard materials or removing
screws: Select a high level.
For drilling operation: Turn the torque
sleeve to the
[ 3 ]
˜ Switching on and off
NOTE
The on/off switch
6 ] [
Switching on: Press and hold the on/off
switch .
6 ] [
Regulate the speed as required (see "Speed
control") (fig. I).
Switching off: Release the on/off
switch .
[ 6 ]
˜ Speed control
By using the on/off switch
progressively control the speed:
Pressure
Gentle pressure:
Greater pressure:
˜ LED work light
This product is equipped with a LED work light
to illuminate the immediate working area to
improve visibility in poorly lit areas.
The LED work light
as soon as the product is switched on.
NOTE
The LED work light
u
additional approx. 10 seconds after
switching off the product.
˜ Working instructions
Torque
Smaller screws/bits can be damaged if you
set the torque or rotational speed too high.
44 GB/IE
position.
cannot be locked.
, you can
6 ] [
Speed
Lower speed
Higher speed
lights up automatically
[ ]
stays on for an
[ ]
Hard screw joints (in metal)
Particularly high torque occurs, for example in
metal screw joints made using drive sockets.
Select a low rotational speed.
Soft screw joints (e.g. in soft wood)
Again, use a low rotational speed, e.g. to
avoid damaging the surface of the wood
upon contact with the screw head. Use a
countersink.
Drilling in wood, metal and other
materials
Use a high speed for drill bits with small
diameter and a low speed for drill bits with
large diameter.
Select a low speed for hard materials and a
high speed for soft materials.
Secure or fasten the workpiece in a clamp or
vice (if possible).
Mark the spot where you want to drill using a
centre punch or nail. Select a low rotational
speed when starting.
Pull the rotating drill bit from the hole
repeatedly to remove dust and chips and
clear the hole.
Drilling in metal
[ ]
Use a metal drill (HSS). For optimum results,
cool the drill bit with cooling lubricant (cutting
oil). Metal drill bits can also be used to drill
into plastics. Start with a 3 mm diameter drill
bit and then increase the size until the desired
hole diameter is achieved.
Drilling in wood
Use a wood drill with a lathe centre.
Deep holes: Use an auger bit.
Large-diameter holes: Use a Forstner bit.
Small screws can be screwed directly into soft
wood.
