GRAPHITE 58G492 Benutzerhandbuch Seite 9

Serwis Centralny GTX Service Sp. z o.o. Sp.k.
ul. Pograniczna 2/4 tel. +48 22 364 53 50 02-285 Warszawa e-mail
bok@gtxservice.com
Sieć Punktów Serwisowych
pogwarancyjnych dostępna na platformie internetowej gtxservice.pl
Zeskanuj QR kod i wejdź na gtxservice.pl
Deklaracja zgodności WE
Producent: Grupa Topex Sp. Z o.o. Sp.k., ul. Pograniczna 2/4 02-285
Warszawa
Wyrób: Pilarka tarczowa
Model: 58G492
Nazwa handlowa: GRAPHITE
Numer seryjny: 00001 ÷ 99999
Niniejsza deklaracja zgodności wydana zostaje na wyłączną
odpowiedzialność producenta.
Opisany wyżej wyrób jest zgodny z następującymi dokumentami:
Dyrektywa Maszynowa 2006/42/WE
Dyrektywa o Kompatybilności Elektromagnetycznej 2014/30/UE
Dyrektywa RoHS 2011/65/UE zmieniona Dyrektywą 2015/863/UE
Oraz spełnia wymagania norm:
EN 62841-1:2015; EN 62841-2-5:2014;
EN 55014-1:2017; EN 55014-2:2015; EN IEC 61000-3-2:2019; EN
61000-3-3:2013+A1;
IEC 62321-3-1:2013; IEC 62321-4:2013+AMD1:2017; IEC 62321-
5:2013;
IEC 62321-6:2015; IEC 62321-7-1:2015; IEC 62321-7-2:2017; IEC
62321-8:2017
Deklaracja ta odnosi się wyłącznie do maszyny w stanie, w jakim została
wprowadzona do obrotu i nie obejmuje części składowych
dodanych przez użytkownika końcowego lub przeprowadzonych przez niego
późniejszych działań.
Nazwisko i adres osoby mającej miejsce zamieszkania lub siedzibę w UE
upoważnionej do przygotowania dokumentacji technicznej:
Podpisano w imieniu:
Grupa Topex Sp. Z o.o. Sp.k.
Ul. Pograniczna 2/4
02-285 Warszawa
Paweł Kowalski
Pełnomocnik ds. jakości firmy GRUPA TOPEX
Warszawa, 2020-06-18
TRANSLATION (USER) MANUAL
CIRCULAR SAW 58G492
NOTE: READ THIS MANUAL CAREFULLY BEFORE USING THE
POWER TOOL AND KEEP IT FOR FUTURE REFERENCE.
SPECIFIC SAFETY PROVISIONS
SPECIFIC SAFETY FOR CIRCULAR SAWS WITHOUT RIVING
KNIFE
Cutting procedure
• DANGER: Keep hands away from the cutting area and the cutting
disc. Keep the other hand on the auxiliary handle or on the motor
housing. If you hold the saw with both hands, you reduce the risk of
injury from the cutting disc.
• Do not reach under the underside of the workpiece with your
hand. The guard cannot protect you from the rotating cutting disc
below the workpiece.
• Set the depth of cut appropriate to the thickness of the workpiece.
It is recommended that the cutting disc extends below the material to
be cut to less than tooth height.
• Never hold the workpiece to be cut in your hands or on your leg.
Fix the workpiece to a solid base. Good clamping of the workpiece
do napraw gwarancyjnych
EN
is important to avoid the danger of contact with the body, jamming of
the rotating cutting disc or loss of cutting control.
• Hold the saw by the insulated surfaces intended for this
i purpose during work where the rotating cutting wheel may
come into contact with live wires or the saw's power cord.
Contact with "live wires" of metal parts of the power tool may cause the
operator to receive an electric shock.
• Always use a slitting guide or edge guide when slitting. This
improves cutting accuracy and reduces the possibility of jamming of the
rotating cutting disc.
• Always use a cutting disc with the correct size of mounting holes.
Cutting discs that do not fit into the mounting slot may run
eccentrically, causing a loss of work control.
• Never use damaged or inappropriate washers or screws to attach
the cutting disc. The washers and bolts securing the cutting disc
have been specially designed for the saw to ensure optimum
function and safety in use.
Causes of discard and prevention of discard.
• Rear kickback is the sudden lifting and withdrawal of the saw towards
the operator in the line of cut, caused by a jammed or improperly
guided cutting blade.
• When the saw blade is snagged or clamped in a slot, the cutting
disc stops and the motor reaction causes the saw to move rapidly
backwards towards the operator.
• If the cutting disc is twisted or misaligned in the workpiece being cut,
the teeth of the cutting disc, on exiting the material, may strike the upper
surface of the material being cut, causing the cutting disc and
therefore the saw to lift and kick back towards the operator.
Rear kickback is the result of improper use of the chainsaw or
incorrect operating procedures or conditions and can be avoided by
taking appropriate precautions.
•
Hold the saw with both hands firmly, with the arms
positioned to withstand the force of rear kickback. Assume a
body position on one side of the saw, but not in the line of cut.
• Rear kickback can cause the saw to move rapidly backwards, but the
force of the rear kickback can be controlled by the operator if appropriate
precautions are taken.
• When the cutting disc jams or when it stops cutting for any
reason, release the switch button and hold the saw stationary in
the material until the cutting disc stops completely. Never attempt
to remove the cutting disc from the cut material, or pull the saw
backwards as long as the cutting disc is moving can cause rear
kickback. Investigate and take corrective action to eliminate the cause of
the cutting disc seizing.
• When restarting the saw in the workpiece, centre the cutting disc
in the cut and check that the teeth of the cutting disc are not
jammed in the material. If the cutting disc jams when the saw is
restarted, it may slide out or cause backlash against the workpiece.
• Support large plates to minimise the risk of clamping and rear
kickback of the saw. Large slabs tend to bow under their own
weight. Supports should be placed under the slab on both sides, near
the cutting line and close to the edge of the slab.
• Do not use dull or damaged c u t t i n g discs. Unsharpened or
misaligned cutting disc teeth create a narrow cut causing excessive
friction, jamming of the cutting disc and back recoil.
• Set the cutting depth and tilt angle clamps securely before making
the cut. If the saw settings change during cutting this can cause
jamming and back kickback
• Be particularly careful when making plunge cuts in partitions. The
cutting disc may cut other objects not visible from the outside, causing
rear recoil.
Bottom cover functions
• Check the bottom guard before each use to ensure that it is
correctly retracted. Do not use the saw if the bottom guard does
not move freely and does not come off immediately. Never attach
or leave the bottom guard in the open position. If the saw is
accidentally dropped, the bottom guard may be bent. Lift the bottom
guard using the pull-back handle and ensure that it moves freely and
does not touch the cutting blade or any other part of the machine for
each angle and depth of cut setting.
• Check the function of the bottom guard spring. If the guard and
spring are not working properly, they should be repaired before
use. Triggering of the bottom guard can be slowed down by damaged
parts, sticky deposits, or build-up of waste.
• Manual withdrawal of the bottom guard is only permitted for
special cuts such as "plunge cuts" and "compound cuts". Raise
the bottom guard with the pull-back handle and when the
5
