DIMENSIONI D'INGOMBRO, DISTRIBUZIONE
PESI E SPAZI DI RISPETTO - VERSIONE MS
ABMESSUNGEN, GEWICHTSVERTEILUNG,
SERVICE FREIRÄUME - BAUVARIANTEN MS
1800 mm
1000 mm
1000 mm
182-R
MOD.
MS
A mm 2926
B mm 2200
C mm 2126
D mm 245
G mm 200
H mm 800
I mm 926
182-R
MOD.
MS
K1 Kg 190
K2 Kg 170
K3 Kg 180
K4 Kg 160
K5 Kg 165
K6 Kg 150
K7 Kg 160
K8 Kg 145
K9 Kg ---
K10 Kg ---
Tot. Kg 1320
N° 1
16
A
1000 mm
202-R 242-R
MS MS
2926 2926
2200 2200
2126 2126
245 245
200 200
800 800
926 926
202-R 242-R
MS MS
200 210
170 175
190 200
160 160
170 180
150 155
165 165
145 150
--- ---
--- ---
1350 1395
VENTILATORI / FANS / LÜFTERN / VENTILATEURS
1 2
DIMENSIONS, WEIGHTS AND
CLEARANCES - MS VERSIONS
DIMENSIONS, DISTRIBUTION DES POIDS,
ESPACES TECHNIQUES - MS VERSION
K1
K5
G
K1
K6
Spazi di rispetto
Clearance area
Service Freiräume
G
Espces Techniques
262-R 302-R
MS MS
2926 2926
2200 2200
2126 2126
245 245
200 200
800 800
926 926
262-R 302-R
MS MS
215 225
175 190
210 220
160 175
185 200
155 165
165 185
150 155
--- ---
--- ---
1415 1515
2 2
D
C
B
X
K2 K3 K4
K6 K7 K8
8xØ18
X
H I H G
100
A
X
K4 K5
K2 K3
K7 K8 K9 K10
10xØ18
X
H I I H
G
A
363-R 393-R
MS MS
2926 3926
2200 2200
2126 2126
245 245
200 200
800 882
926 881
363-R 393-R
MS MS
240 225
200 180
235 220
180 180
220 210
170 175
205 205
160 175
--- 200
--- 170
1610 1940
2 2
X-X
100
X-X
453-R
MS
3926
2200
2126
245
200
882
881
453-R
MS
240
190
230
190
225
185
220
185
215
180
2060
3
