Connection with the mains
Connect the device to the mains with the enclosed power supply cable.
The occupation of the connection-cables is as follows:
Cable Pin
Brown Live
Blue Neutral
Yellow/Green Earth
The earth has to be connected!
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC-
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.
Lighting effects must not be connected to dimming-packs.
OPERATION
With the power switch, you can switch the device on and off.
After you connected the effect to the mains, the LED MFX-3 Action Cube starts running. During the Reset,
the motors are trimmed and the device is ready for use afterwards.
Stand-alone operation
In the Stand-alone mode, the LED MFX-3 Action Cube can be used without controller.
Disconnect the LED MFX-3 Action Cube from the controller and call the internal program. Please refer to the
instructions under Control Board.
Master/Slave operation
The master/slave operation enables that several devices can be synchronized and controlled by one master-
device.
On the rear panel of the LED MFX-3 Action Cube you can find an XLR-jack (DMX Out) and an XLR-plug
(DMX In), which can be used for connecting several devices.
Choose the device which is to control the effects. This device then works as master device and controls all
other slave devices, which are to be connected to the master device via a DMX cable. Connect the DMX
OUT jack with the DMX IN plug of the next device.
Set the master mode for the master device. Set the slave mode for all slave devices, as described in chapter
Control Board under menu "Slnd".
DMX-controlled operation
You can control the projectors individually via your DMX-controller.
Every DMX-channel has a different occupation with different features. The individual channels and their
features are listed under DMX-protocol.
International
L
N
