Control Board

The Control Board offers several features: you can simply set the starting address or run the pre-
programmed program.
The main menu is accessed by pressing Menu until the display is lit. Browse through the menu by pressing
Up or Down. Press Enter in order to select the desired menu. You can change the selection by pressing Up
or Down. Press Enter in order to confirm. You can leave every mode by pressing Menu. The functions
provided are described in the following sections.
Menu
Addr
Chnd
Shnd
Slnd
Lost
Sens
Angl
Pint
Tint
Manu
Led
disp
Test
Fhrs
Ver
Rest
defa
Sub menu
000-512 DMX address setting
14Ch
Setting DMX channel mode
16Ch
Sh1
Sh2 Internal programs
Sh3
Mast Master setting
SL1 Slave setting
Hold
Soun
If no DMX-signal one of these modes will run
Auto
Blac
S000~S099 Microphone sensitivity (increasing)
630 Select PAN-angle
540 630° or 540°
Yes
No
Reverse movement PAN/TILT
Yes
No
Pan
Til
Til2
Red
Gren Function test of individual channels (000-255)
Settings are lost when the device is switched off.
Blue
Whit
Stro
Dim
led
on
LED on/off
off
on
Display reverse 180 degree
off
Function test
Fixture running time
Software version
Reset
Restore factory settings
Function
