S/N
Name
36
Type B circlip 25
38
Bearing 2516
39
Down pulley
40
Slider
41
Pulling rod
42
Pressure spring
43
Teeth block
44
Elastic pin 5*35
45
Type B circlip 22
46
Pin shaft assembly
47
Cross socket flat head screw M8*16
48
Protection rubber pad
49
Carriage assembly
Druckfehler, Irrtümer und Änderungen vorbehalten.
Handbuch 2-Säulenhebebühne Garagenmodell TW242GE
Drawing
GB/T894.2-1986
SF-1
FL-8224T-A1-B2
FL-8224T-A3-B2
FL-8224-A3-B2
FL-8224-A3-B5
FL-8224-A3-B6
GB/T879.1-2000
GB/T894.2-1986
FL-8224E-A12
GB/T819.1-2000
FL-8224-A3-B7
FL-8224SE-A3-B1
Qty
Property
4
Standard
4
Standard
4
Zinc-plating
16
Nylon
4
Zinc-plating
4
Zinc-plating
4
Zinc-plating
4
Standard
4
Standard
4
Zinc-plating
4
Standard
2
Rubber
2
Welded
Note
Seite | 35
