2.2.

Model with Quick-Fill Coupling (BD 96 SL-Q)

Besides the standard unit fittings, this model also comes with a high pressure
safety coupling (see Pos. 3 in Fig. 2).It is then possible to fill 300 bar compressed
air cylinder(s) whilst the compressed air breathing apparatus is in use.
Warning!
In compressed air breathing apparatus with Quick-Fill couplings the use
of 200 bar compressed air cylinders is not permitted.
2.3.

Technical Data

High pressure connection
Medium pressure
Operating temperature
Weight (approx.)
Dimensions (approx.)
Approvals
GB
: 200 bar resp. 300 bar
: 5 bar to 9 bar
: -30°C to +60°C
: 3.8 kg
: Length 585 mm
Width 290 mm
Height 145 mm
: The compressed air breathing apparatus
conforms to the Directives 89/686/EEC and
94/9/EG. It is a container unit with compres-
sed air in accordance with EN 137.
ATEX
BVS 03 ATEX H 010 X
IM1c
II 1 G c IIC T6 -30°C ≤ Ta ≤ +60°C
II 1 D c
0158
BD 96 SL
