Scheppach HPC 1400 Originalbetriebsanleitung Seite 25

4. Switch the product on with the On/Off switch (3).
Always switch on the product only after you have
connected all the water lines and they are leak-
tight. The motor switches on until the necessary
pressure is built up. After pressure build-up, the
motor switches off.
5. Unlock the trigger (14) with the unlocking button (15).
6. Press the trigger (14) on the spray gun (13). The
product motor starts automatically.
7. By releasing the trigger (14), the product switches
off, the high pressure in the system is maintained.
11.2 Stop operation
1. Switch the product off with the On/Off switch (3).
Pull out the mains plug.
2. Turn off the water tap.
3. Disconnect the high-pressure cleaner from the
water supply.
4. Press the trigger (14) of the spray gun (13) to
release the existing pressure in the system.
11.3 Self-priming function
You can also use the product independently of the
water supply (e.g. rain barrel) thanks to the integrated
water suction function. This function can only be used
with a suction hose with filter basket (not included in the
scope of delivery).
m WARNING! The product itself must not be immersed
in the open water source. There is a risk of persons
being injured due to electric shock.
1. Plug the suction hose with filter basket onto the
water connection coupling (19).
2. Hang the end with the filter basket into the water
extraction point. Make sure you have a sufficient
water supply and a safe water supply.
NOTE: Running dry will damage the product.
3. Remove the lance (12) from the spray gun (13).
Press the trigger (22) of the spray gun (9) and only
then switch on the product.
4. The product starts to draw in water and the air can
escape.
5. When there is no more air in the product, you can
release the trigger (14) of the spray gun (13). You
can connect the attachment of your choice to the
spray gun (13).
NOTE: The product should not be higher than the
water take-off point.
12. Transport (Fig. 1)
It can be easily transported with the help of the bracket
handle (1).
13. Cleaning and maintenance
m WARNING! Disconnect the mains plug before any
work on the product. This includes connecting to the
water supply or trying to fix leaks.
There is a risk of electric shock or injury from moving
parts.
13.1 Maintenance
The high-pressure cleaner is maintenance-free.
13.2 Cleaning
m WARNING! Do not spray the product with water
or clean it under running water. There is a danger of
electric shock and the product could be damaged.
• Keep protective devices, air vents and the motor
housing as free of dust and dirt as possible. Rub the
product clean with a clean cloth or blow it off with
compressed air at low pressure.
• We recommend that you clean the product directly
after every use.
• Clean the product at regular intervals using a damp
cloth and a little soft soap. Do not use any cleaning
products or solvents; they could attack the plastic
parts of the product. Make sure that no water
can penetrate the interior of the product. Water
penetration increases the risk of an electric shock.
You can remove foreign objects from clogged nozzles
with the nozzle cleaning needle (21).
Rinse the nozzles with water to remove foreign objects.
14. Storage (Fig. 3)
• Store the product and its accessories in a dark, dry
and frost-free place that is inaccessible to children.
• Wind the mains cable (4) onto the holder for the
mains connection cable (2).
• Stow the accessories on the accessories mounting
bracket (7) and the high-pressure hose (18) on the
high-pressure hose mounting bracket (8)
• The optimum storage temperature is between 5 and
30˚C.
• Store the product in its original packaging.
www.scheppach.com GB | 25
