WARNING
The noise emission values and vibration
emission value can vary from the specified
values during the actual use of the power
tool, depending on the type and the manner
in which the electric tool is used, and in par-
ticular the type of workpiece being pro-
cessed.
Try to keep the stress as low as possible. For example:
Limit working time. In doing so, all parts of the operating
cycle must be taken into account (such as times in
which the power tool is switched off or times in which it
is switched on, but is not running under a load).
7
Unpacking
WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suffo-
cating!
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
8
Before commissioning
WARNING
Danger of injury!
Remove the battery from the power tool before carrying
out any work on the power tool (e.g. maintenance, tool
change, etc.) and when transporting and storing it.
There is a risk of injury if the on/off switch is operated
unintentionally.
8.1
Inserting/removing the battery (9)
in the battery mount (8) (Fig. 1, 2)
Inserting the battery
1. Push the battery (10) into the battery mount (9). The
battery (10) clicks into place audibly.
Removing the battery
1. Press the unlock button (11) of the battery (10) and
remove it from the battery mount (9).
8.2
Fitting/replacing the saw blade (1)
(Fig. 3)
1. Turn the quick-clamp chuck (4) as far as it will go and
hold it in this position.
2. Push the required saw blade (1) into the quick-clamp
chuck (4) as far as it will go.
3. Release the quick-clamp chuck (4), it must return to
its original position. The saw blade (1) is now locked.
ATTENTION
The teeth of the saw blade must point downwards.
8.3
Adjusting the foot plate (2) (Fig. 4)
WARNING
Tool attachments may be sharp and become hot during
use. Always wear protective gloves when handling the
tool attachments.
CAUTION
–
Remove the saw blade from the product before ad-
justing the foot plate.
–
Do not use the product without the footplate in
place.
To adapt to the workpiece, the foot plate (2) can be ad-
justed into various positions and swivelled.
Unlock the foot plate:
1. Turn the unlocking lever (3) counter-clockwise.
2. Adjust the desired position of the foot plate (2) by pull-
ing it in or out.
Lock the foot plate:
1. Turn the unlocking lever (3) clockwise.
9
Operation
WARNING
Danger of injury!
Remove the battery from the power tool before carrying
out any work on the power tool (e.g. maintenance, tool
change, etc.) and when transporting and storing it.
There is a risk of injury if the on/off switch is operated
unintentionally.
ATTENTION
Make sure that the ambient temperature does not ex-
ceed 50°C and does not fall below -20°C during work.
ATTENTION
The product is part of the 20V IXES series and may on-
ly be operated with batteries of this series. Batteries
may only be charged with battery chargers of this se-
ries. Observe the manufacturer's instructions.
www.scheppach.com
GB | 19
