286
Anhang C: MIDI
0bbbbbbb bh
0bbbbbbb bl
EOX 11110111 F7
12.2.29 Output patch library bulk dump format
The second and third bytes of the DATA NAME indicate the library num-
ber.
0:Library no.0 - 32:Library no.32, 256:current output patch data
For reception by the 02R96, only the user area is valid. (1-32, 256)
STATUS 11110000 F0
ID No. 01000011 43
SUB STATUS 0000nnnn 0n
FORMAT No. 01111110 7E
COUNT HIGH 0ccccccc ch
COUNT LOW 0ccccccc cl
01001100 4C
01001101 4D
00100000 20
00100000 20
00111000 38
01000011 43
00110101 35
00110100 34
DATA NAME 01001111 4F
0bbbbbbb bh
00100000 bl
BLOCK INFO. 0ttttttt tt
0bbbbbbb bb
DATA 0ddddddd ds
: :
0ddddddd de
CHECK SUM 0eeeeeee ee
EOX 11110111 F7
12.2.30 Output patch library bulk dump request format
The second and third bytes of the DATA NAME indicate the library num-
ber.
0:Library no.0 - 32:Library no.32, 256:current output patch data
STATUS 11110000 F0
ID No. 01000011 43
SUB STATUS 0010nnnn 2n
FORMAT No. 01111110 7E
01001100 4C
01001101 4D
00100000 20
00100000 20
00111000 38
01000011 43
00110101 35
00110100 34
DATA NAME 01001111 4F
0bbbbbbb bh
0bbbbbbb bl
EOX 11110111 F7
12.2.31 Bus to Stereo library bulk dump format
The second and third bytes of the DATA NAME indicate the library num-
ber.
0:Library no.0 - 32:Library no.32, 256:current data
For reception by the 02R96, only the user area is valid.
STATUS 11110000 F0
ID No. 01000011 43
SUB STATUS 0000nnnn 0n
FORMAT No. 01111110 7E
COUNT HIGH 0ccccccc ch
COUNT LOW 0ccccccc cl
01001100 4C
02R96—Bedienungsanleitung
0-32(Library no.0-32), 256(Current
data)
End of exclusive
System exclusive message
Manufacture's ID number (YAMAHA)
n=0-15 (Device number=MIDI Channel)
Universal bulk dump
data count = ch * 128 + cl
'L'
'M'
' '
' '
'8'
'C'
'5'
'4'
'O'
0-32(Library no.0-32), 256(Current
data)
total block number(minimum number
is 0)
current block number(0-total block
number)
Input Patch Library data
ee=(Invert('L'+...+de)+1)&0x7F
End of exclusive
System exclusive message
Manufacture's ID number (YAMAHA)
n=0-15 (Device number=MIDI Channel)
Universal bulk dump
'L'
'M'
' '
' '
'8'
'C'
'5'
'4'
'O'
0-32(Library no.0-32), 256(Current
data)
End of exclusive
System exclusive message
Manufacture's ID number (YAMAHA)
n=0-15 (Device number=MIDI Channel)
Universal bulk dump
data count = ch * 128 + cl
'L'
'M'
01001101 4D
' '
00100000 20
' '
00100000 20
'8'
00111000 38
'C'
01000011 43
'5'
00110101 35
'4'
00110100 34
'J'
DATA NAME 01001010 4A
0-32(Library no.0-32), 256(Current
0bbbbbbb bh
data)
0bbbbbbb bl
total block number(minimum number
BLOCK INFO. 0ttttttt tt
is 0)
current block number(0-total block
0bbbbbbb bb
number)
Input Patch Library data
DATA 0ddddddd ds
: :
0ddddddd de
ee=(Invert('L'+...+de)+1)&0x7F
CHECK SUM 0eeeeeee ee
End of exclusive
EOX 11110111 F7
12.2.32 Bus to Stereo library bulk dump request format
The second and third bytes of the DATA NAME indicate the library num-
ber.
0:Library no.0 - 32:Library no.32, 256:current data
System exclusive message
STATUS 11110000 F0
Manufacture's ID number (YAMAHA)
ID No. 01000011 43
n=0-15 (Device number=MIDI Channel)
SUB STATUS 0010nnnn 2n
Universal bulk dump
FORMAT No. 01111110 7E
'L'
01001100 4C
'M'
01001101 4D
' '
00100000 20
' '
00100000 20
'8'
00111000 38
'C'
01000011 43
'5'
00110101 35
'4'
00110100 34
'J'
DATA NAME 01001010 4A
0-32 (Library no.0-32), 256 (Current
0bbbbbbb bh
data)
0bbbbbbb bl
End of exclusive
EOX 11110111 F7
12.2.33 Surround Monitor library bulk dump format
The second and third bytes of the DATA NAME indicate the library num-
ber.
0:Library no.0 - 32:Library no.32, 256:current data
For reception by the 02R96, only the user area is valid. (1-32, 256)
System exclusive message
STATUS 11110000 F0
Manufacture's ID number (YAMAHA)
ID No. 01000011 43
n=0-15 (Device number=MIDI Channel)
SUB STATUS 0000nnnn 0n
Universal bulk dump
FORMAT No. 01111110 7E
data count = ch * 128 + cl
COUNT HIGH 0ccccccc ch
COUNT LOW 0ccccccc cl
'L'
01001100 4C
'M'
01001101 4D
' '
00100000 20
' '
00100000 20
'8'
00111000 38
'C'
01000011 43
'5'
00110101 35
'4'
00110100 34
'K'
DATA NAME 01001011 4B
0-32(Library no.0-32), 256(Current
0bbbbbbb bh
data)
0bbbbbbb bl
total block number(minimum number
BLOCK INFO. 0ttttttt tt
is 0)
current block number(0-total block
0bbbbbbb bb
number)
Input Patch Library data
DATA 0ddddddd ds
: :
