Speak to you local specialist regarding the correct screws and dowels
for fixture to the house wall.
Fix the connecting element to the frame of the screen by first of all
loosening the frame screws and then fixing it in place again using the
frame screws.
1
Next, mark the holes to be drilled on the wall.
2
Lift the screen out of its floor fixture. Then drill the holes into the
house wall.
3
Remove the pre-assembled connecting element so that only an
L-bracket remains in the frame.
Fit the second L-bracket in the holes drilled into the house wall.
4
28
Ensure that the L-bracket pointing upwards is always fixed to the
element.
Lift the screen back into the floor fixture.
5
Insert the round part.
6
Fix the connecting element with the screw provided.
7
Do not forget to screw the elements back into the floor fixture properly!
