The inputs IN1-IN5 are optocoupled. (UIN = 18 to 27Vdc,
ZIN input impedance = 2000Ω).
The outlets OUT1-OUT3 do not have galvanic isolation
(UOUT = 24Vdc, IOUT = 300mA).
The AOK serves to separate the power circuit on the in-
put side from the regulator by means of a controlled elec-
tric contactor, if the regulator causes an error. (UMAX =
50Vdc, IMAX = 300mA).
The STO inputs are optocoupled. (UIN → signal level 0:
-3V to 5Vdc, signal level 1: 15V to 30Vdc, ZIN input imped-
ance = 4500Ω).
3. h
aNDlINg
3.1 s
peed rAnge
3.1.1 c
OnfigurAtiOn Of externAl speed selectiOn
ai s m n086 m
iGnal otor
0V 0rpm
10Vdc 10000rpm
Using the analog voltage 0 to 10V, the speed of the motor
can be selected freely between 0 and maximum rotation
speed. Using Signal X2.24 (IN4) a rotation direction can
be selected. The rotation direction is changed according
to case 5 (see I/O time flowchart). Acceleration/delay
500ms
Due to heat generation, it is recommended to operate the
motor in continuous operation (S1) only up to 7000rpm.
3.1.2 c
OnfigurAtiOn Of the sequence mOde
in4-s m
iGnal otor
Low 3000rpm
high 5000rpm
In the configuration of the sequence mode, the analog
input X2.11 (AI) and X2.02 (AI GND) is without function.
Rotation speed can be selected using two sequences at
input X2.24 (IN4). The speed sequence is changed accor-
ding to case 5 (see I/O time flowchart).
26
/o
PERaTIoN
ln086 m ln098
otor otor
0rpm 0rpm
5000rpm 2400rpm
ln086 m ln098
otor
+2400rpm
-2400rpm
3.2 g led
OVernOr displAy
s
e
tatUs
rror
Off No error
Flashes
Undervoltage
(250ms on/
250ms off)
On Error
r
Un
Flashes / On
3.3 t

OOl chAnge

The switched-on regulator causes an error if the connec-
tion to the temperature sensor is interrupted. Therefore
proceed as follows to change a tool:
1) Stop the motor (IN2 = Low, IN3 = High)
2) Deactivate the motor (IN1 = Low)
3) Change the tool
4) Acknowledge error (Pulse on IN5 (Low → High → Low))
5) Check for presence of errors (OUT = Low)
6) Activate motor (IN1 = High)
7) Start motor (IN2 = High)
4. S
ERvIcE
4.1 p m
reVentiVe AintenAnce
Before any maintenance or servicing work,
the partly completed machinery must
have been disconnected from the power
supply for 5 minutes and secured against accidental re-
activation (e.g. with a padlock).
4.2 t

rOuBleshOOting

In the event of malfunctions, contact an authorized after-
sales SUHNER service center.
4.3 r
epAir
If despite strict observance of the manufacturing and test-
ing method the partly completed machinery should hap-
pen to fail, it must be repaired by an authorized SUHNER
d
escription
Governor ready
The voltage supply
(power circuit) is missing.
Error occurred
Governor deactivated
AOK relay contact open
Possible errors:
Motor temperature sensor
not connected
24Vdc voltage supply
(control circuit) too high/
low
Motor overheated
Short circuit
s
tatUs
Governor ready for opera-
tion
/m
aINTENaNcE
