ENGLISH

10 HMI installation - remote control display

For code 12214 (VORT INVISIBLE MINI TOP) the SCP503 wall box, including the aesthetic plate, is already
included in the supply. For flush mounting of the display relating to code 12214, it is possible to order the flush
box (cod. 22461).
SCP503 box (with plate) Accessory: built-in box
already present in the supply of the cod. 12214 (cod. 22461)
For the other codes in the VORT INVISIBLE MINI range, the SCP DIN installation box (code 12898) can be
ordered as an accessory for wall mounting of the HMI remote display.
Accessory: SCP
DIN wall box 12215 12216 12218 12219
(cod. 12898)
● ● ● ●
- ATTENTION: The installation of the remote control panel box must
be carried out only by professionally qualified personnel.
13
43
