Installation

NOTE: Installation must be performed by competent personnel in accordance with the authorities involved and
in compliance with all applicable regulations and standards.
When the unit position has been decided, secure it with the 2 fixing brackets levelled (fig.2). Use screws suitable
for the surface on which it is fixed.
NOTE: For better air distribution on the surface of the filters, insert them as shown in fig.3.
NOTE: During installation, do not place the product with the side of the electronic card facing the wall, as it could
create problems during maintenance.
2
Fixing brackets
3
38
Filters:
