2.2 Installing and Connecting

2.2.1 Requirements and Notes

Computer Requirements

The CP 5611 A2 module is a plug and play network card

for devices with a 32-bit PCI bus interface conforming with

the PCI V2.2 specification.

The CP 5611 A2 is universally coded according to the PCI

standard, in other words 3.3 and 5 V slots are supported.

PCI-X slots with 32 or 64 bits are also supported. The

module has the dimensions of a short PCI module

(102 mm x 130 mm).

Note

For the DP mode, at least a 166 MHz Pentium processor

or comparable processor is recommended.

Software Requirements

The software for operating the module is not supplied with

the module. You can order this from your Siemens contact.

Possible Number of CP 5611 Modules in One Computer

A maximum number of two CP 5611 modules are permitted

in a PG/PC at the same time.

Installation Instructions CP 5611 A2

A5E00469482-01

6gk1561-1aa01
