To install and attach the CP 5611 A2 follow the steps out-
lined below:
Step
1 Turn off your computer and pull out the power
cable connector from the socket.
2 Open the computer housing as described in the
manual for your PG/PC.
3 Insert the CP 5611 A2 in a PCI slot.
Make sure that the CP 5611 A2 sits firmly and
uniformly in the slot.
Notice
When handling the module, do not touch the
terminals or the electronic components.
4 Close the computer housing as described in the
manual for your PG/PC.
5 Reinsert the power supply connector in the
socket and turn on your computer.
48
Installation Instructions CP 5611 A2
Procedure
Installation Instructions CP 5611 A2
A5E00469482-01
