Installation Instructions CP 5611 A2
Components of the Supplied Product
The following components are supplied with the
CP 5611
A2:
● CP 5611 A2 communications processor
● Hardware Installation Instructions / Product Information
Bulletin in German and English
● Packaging
MPI/DP Network
With the CP 5611 A2 communications processor, up to
32 devices (PC, PG, SIMATIC S7 or ET 200) can be con-
nected together to form a network segment. By coupling
several segments with repeaters, a maximum of 127 nodes
can be connected.
The physical coupling of the MPI/DP interface to the
MPI/DP network is over a floating RS-485 interface that is
part of the module. Depending on the network configuration
in the MPI/DP network, data transmission rates of 9.6 Kbps
up to maximum of 12 Mbps are possible.
Note
For information on the configuration of an MPI network,
refer to the manual "S7–300 Hardware and Installation",
order number 6ES7030-0AA01–8BA0.
