Der Speicher des CMC600 wird gelöscht.
Im Dialogfenster zeigt CLV-Setup den Status des Löschvor-
gangs.

5.3 Weitere Funktionen bei Neustart

Ohne CMC600 im Anschlussmodul/bei Ausfall des CMC600:
Der Sensor verwendet die Parameterwerte seines internen
Parameterspeichers.
CMC600 enthält Parameterwerte eines anderen Sensortyps:
Der Sensor verwendet die Werte seines internen Parameter-
speichers und übernimmt nur die Schalterstellungen des
CMC600.
Das CMC600 enthält Parameterwerte des gleichen Sensortyps
jedoch aus einer unterschiedlichen Firmware-Version stam-
mend: Der Sensor lädt die Parameterwerte aus dem CMC600
und übernimmt die Schalterstellungen.
6. Zusätzliche Schaltein- und -ausgänge
Das CMC600 unterstützt die Sensoren wie folgt:
Sensor
Zusätzliche Eingänge
CLV6xx (nicht CLV69x) 2
Lector
620
2
®
RFH6xx/RFU63x
2
JFE300
2
CLV42x ... 45x
2
CLV480/CLV/X490
ICR84x-2/ICR85x-2

7. Technische Daten

Typ
CMC600-101 (Nr. 1042259)
Unterstützte ID-Sensoren
CLV62x
CLV63x
CLV64x
CLV65x
Lector
RFH6xx
RFU63x
JEF300/500
CLV42x
CLV43x ... 45x
CLV480/ CLV/X490 (ab Firmware V. 3.30)
ICR84x-2/85x-2
Basisgeräte für CMC600
CDB620 (alle Typen),
(Anschlussmodule)
CDM420
Typen)
Zusätzliche Schalteingänge 2 , opto-entkoppelt, U
Zusätzliche Schaltausgänge 2, PNP, I
Optische Anzeigen
2 x LED
Versorgungsspannung
DC 10 ... 30 V, über CDB/CDM
Leistungsaufnahme
500 mW
Gehäuse/Prüfzeichen
Polycarbonat/CE
IEC 61010-1:2010 + Cor.:2011
Elektrische Sicherheit
EMV-Prüfung
Nach EN 61000-6-2 (2005-08-01),
EN 61000-6-3 (2007-01-01)
Gewicht
Ca. 12 g
Temperatur (Betrieb/Lager) –35 ... +40 °C/–35 ... +70 °C
Kennzeichnung
Abmessungen (L x B x H)
70 mm x 23 mm x 17 mm
*) Besonderheiten siehe 2. Voraussetzungen zur Installation und Inbetriebnahme,
Seite 1.
8015190/1CC7/2021-07
© SICK AG · Germany · All rights reserved · Subject to change without notice · Irrtümer und Änderungen vorbehalten
Zusätzliche Ausgänge
2
2
2
2
(ab Firmware V. 1.00)
(ab Firmware V. 2.00)
(ab Firmware V. 2.51)
(ab Firmware V. 3.00)
620
(ab Firmware V. 1.00)
®
(ab Firmware V. 1.00)
(ab Firmware V. 1.00)
(ab Firmware V. 1.00)
(ab Firmware V. 1.30)
(ab Firmware V. 3.40)
(ab Firmware V. 3.00)
*)
(alle Typen), CDM490
*)
(alle
= max. 32 V
e
= max. 100 mA, kurzschlussfest
a
für Tiefkühltauglichkeit
In the dialog box CLV-Setup displays the status of the opera-
tion.
5.3 Additional Functions at Restart
No CMC600 in the connection module/CMC600 failure:
The sensor uses the parameter values of its internal memory.
CMC600 contains parameter values for a different sensor type:
The sensor uses the parameter values of its internal memory
and only copies the switch settings from the CMC600.
CMC600 contains parameter values for the correct sensor
type, but these were created with a different firmware version:
The sensor loads the parameter values from the CMC600 and
copies the switch settings.
6. Additional switching inputs and outputs
The CMC600 supports the sensors as followed:
Sensor
Additional inputs
CLV6xx (not CLV69x)
2
Lector
620
2
®
RFH6xx/RFU63x
2
JEF300
2
CLV42x to 45x
2
CLV480/CLV/X490
ICR84x-2/ICR85x-2
7. Technical data
Type
CMC600-101 (no. 1042259)
ID sensors supported
CLV62x
CLV63x
CLV64x
CLV65x
Lector
RFH6xx
RFU63x
JEF300/500
CLV42x
CLV43x to 45x
CLV480/CLV/X490 (from firmware V. 3.30)
ICR84x-2/85x-2
Basic devices for CMC
CDB620 (all types),
(connection modules)
CDM420
Additional switch. inputs
2, opto-decoupled, V
Additional switch. outputs 2, PNP, I
Visual indicators
2 x LEDs
Power supply
10 to 30 V DC, via CDB/CDM
Power consumption
500 mW (20 mA at 24 V DC)
Housing/Conformity
Polycarbonate/CE
IEC 61010-1:2010 + Cor.:2011
Electrical safety
EMC tested
To EN 61000-6-2 (2005-08-01)
EN 61000-6-3 (2007-01-01)
Weight
Approx. 12 g (approx. 0.42 oz.)
Temperature
–35 to +40 °C/–35 to +70 °C
(operation/storage)
(–31 to +104 °F/–31 to +158 °F).
Suitability for deep-frozen areas marked by
the
Dimensions (W x H x D)
70 x 23 x 17 mm
*) For details see 2. Installation and Commissioning Requirements, page 1.
Additional outputs
2
2
2
2
(from firmware V. 1.00)
(from firmware V. 2.00)
(from firmware V. 2.51)
(from firmware V. 3.00)
620
(from firmware V. 1.00)
®
(from firmware V. 1.00)
(from firmware V. 1.00)
(from firmware V. 1.00)
(from firmware V. 1.30)
(from firmware V. 3.40)
(from firmware V. 3.00)
(all types), CDM490
(all types)
*)
*)
= max. 32 V
in
= max. 100 mA, short-circuit-proof
out
symbol
(2.76 x 0.9 x 0.67 inch
