Pin assignment

A
8025886/ZC16/2022-10-24 | SICK
Subject to change without notice
Figure 1: Terminals on the power supply plug
Terminal assignment on the power supply plug
Terminal Signal
1 24 V DC
2 –
3 0 V DC
M6 × 8
MOUNTING INSTRUCTIONS
Function
Supply voltage
Reserved
Supply voltage
M O U N T I N G I N S T R U C T I O N S | S3000 PROFINET IO, S3000 PROFINET IO-OF
Wire color for pre-assembled
power supply plug with flying
leads
1
–
2
