MOUNTING INSTRUCTIONS
1

About this document

en
2

Safety information

3

Mounting the device

6 M O U N T I N G I N S T R U C T I O N S | S3000 PROFINET IO, S3000 PROFINET IO-OF
All rights reserved. Subject to change without notice.
This document applies to the safety laser scanner and the associated system plug with
the following part numbers:
System
• 1045650
• 1045651
• 1045652
•
1045653
•
1045654
• 1045655
• 1052591
• 1052592
• 1052593
• 1052594
•
1052595
• 1052596
Symbols and document conventions
A, B References to the figures at the end of this document are indi‐
cated by a black background.
DANGER
Hazard due to lack of effectiveness of the protective device
In the case of non-compliance, it is possible that the dangerous state of the machine
may not be stopped or not stopped in a timely manner.
Observe the enclosed safety notes.
b
You can find detailed information on how to use the product in the machine documen‐
tation or in the operating instructions of the product. You can obtain declarations
of conformity, certificates, and the current operating instructions for the product at
www.sick.com. To do so, enter the product part number in the search field (part
number: see the entry in the "P/N" or "Ident. no." field on the type label).
Mounting the device: A
The device has threaded holes on the rear. They can be used to mount the device
directly if you are able to drill through the mounting surface from behind.
Sensor head
• 2049566
• 2049567
• 2049568
