7.2
Teileliste
Nr.
Hrst. Teilenr.
1
SL70040100
2
SL70040200
3
SL70040300
4
SL70041000V1
5
SL70040500
6
SL70040600
7
SL70040700V1
8
SL70040800
9
SL70040900
10
SL70012800
11
SL70100300
12
SL70010103
13
SL70041300
14
SL70041400
15
SL70012300
16
SL70041600V1
17
SL70013000V1
18
SL7007B2100
19
SL70011100
20
SL70011200
21
SL70011500
22
SL70013100
23
SL70011700
24
SL70011800
25
SL70100400
26
SL70012000
27
SL70042700
28
SL70012100
29
SL70012200
30
SL70012400
31
SL70012500
28
Bezeichnung (ENG)
Left Bottom Frame
Right Bottom Frame
(left/right) Upright Frame
Weight Horn Assembly
Left Arm Frame
Right Arm Frame
Long Cross Frame
Short Cross Frame
Middle Standing Frame
Adjustable Handle
Weight Plate Storage
Narrow Outside Plate
Pivot Plate 1
Pivot Plate 2
Seat Frame
Chest Pad
Seat Pad
Pedal
Front Plastic Plate
Rear Plastic Plate
Pivot Shaft Φ30
Rubber bumper
Domed Aluminium Cap
Long Weight Horn Sleeve
Weight Horn Sleeve
Weight Horn Plastic Cap
Short Aluminium Grip
Aluminium Grip
Pull Spring
Idler Wheel
Wheel Shaft
Spezifi kation
45*200*6
151.4*244.6*10
151.4*244.6*10
441.9*117*6
200*300*70
340*270*70
250*105*25*2
435*107*19
435*107*19
φ30*134
DTφ76*φ42*25
φ54*φ12.5*10.6
φ41.4*φ49*361
φ41.4*φ49*223
φ49*φ12.5*25
φ31*φ25*150
φ31*φ25.4*175
φ31.5*φ2.5*165
φ60*φ40*113.5
φ17*φ12.5*116.5
Low Row
Anz.
1
1
2
2
1
1
1
1
1
1
4
2
2
2
1
1
1
2
1
1
2
2
6
2
4
2
2
2
1
3
3
