eta AQUILO PRO Bedienungsanleitung Seite 49

Item
Cleaning tool
Cleaning brush
Battery
-
(installed in the device)
3.2 ROBOTIC VACUUM CLEANER
A
A9
C
A – Robotic vacuum cleaner
A1 – Front bumper
A2 – Sensors against falling downstairs
A3 – Charging contacts
A4 – Drive Wheels (Left / Right)
A5 – Front wheel
A6 – Side brush
A7 – Main brush
A8 – Main brush cover
A9 – Upper removable lid
A10 – Laser module
A11 – Front sensor
A12 – Rear sensor
A13 – Ultrasonic sensor
Description
A12 A10
A1
A11
Designation
I
J
-
A3
A8
A5
C – Control panel
H – Rotation clips for mops
EN - 49
Quantity Match code
1
ETA724300460
1
ETA724300470
1
ETA724300210
A2
EN
H
A7
A4
A6
A13
