Endress+Hauser promag 30 Ex-Dokumentation Zu Den Betriebsanleitungen Seite 14

en
II2G (ATEX)
Zone 1
Transmitter electronics Promag 30 A/F in:
II3G EEx nAC IIC/IIB T4-T5 X
Transmitter electronics Promag 30 H in:
II3G EEx nAC IIC/IIB T3-T5 X
PRO-LINE housing in IP 67
2
Hazardous area
II3G (ATEX)
PROMAG 30
Sensor A
(DN 2...25)
PROMAG 30
Sensor F
(DN 15...300)
Zone 2
Hazardous area
Sensor Promag A in:
II3G EEx nA IIC/IIB T4-T5 X
• Promag A
Sensor Promag F in:
II3G EEx nA IIC/IIB T4-T5 X
• Promag F
• Promag F
Sensor Promag H in:
II3G EEx nA IIC/IIB T3-T5 X
• Promag H
PROMAG 30
Sensor H
(DN 25...100)
PROMAG 30
Sensor F
(DN 350...1200)
DN 2...25
DN 15...300
DN 350...2000
DN 25...100
Promag 30
Safe area
Safe area
