Instruction CF-MC Master Controller

6. Configuration

6.1 Actuator Outputs

Activate Output mode on Master Controller (fig. 23)
• Use the menu selection button
LED flashes
• Activate Output mode by pressing OK
Select the output configuration
• Press the output selection button
ble output configurations
below:
• 1 LED: The outputs are configured to NC actuators with ON/OFF regu-
lation (default)
•  LEDs: The outputs are configured to NO actuators with ON/OFF
regulation
•  LEDs: The outputs are configured to NC actuators with Pulse Width
Modulation (PWM) regulation for floor heating
• 4 LEDs: The outputs are configured to NO actuators with Pulse Width
Modulation (PWM) regulation for floor heating
• 5 LEDs: A Remote Controller is installed, and it is not possible to
change settings from the Master Controller
• Activate selected output configuration by pressing OK
Note: During periods with no output activations the Master Controller will
run a valve motion program every 2 weeks and it will last for up to 12
minutes. Individual output configuration is possible with Remote Con-
troller, CF-RC, see separate instruction.
16
VI.UH.K1.52
to select the Output mode. Output
and toggle between the possi-
- the output LEDs will be ON – indicated
Produced by Danfoss Floor Heating Hydronics 08.005
. Output LED goes ON
