4 Installation and Use
Table 1 System Requirement
COMPONENT
Anchorage Connector
Harness
Connectors
Structure Strength
COMPONENT
Anchorage Connector Standard
Harness Standard
Connectors Standard
Structure Strength
*Harmonised/Designated Standard
4.1
Fall Clearance
Ensure sufficient clearance exists to prevent striking an obstacle or leading edge (eg crossbeams and
girders) during a fall, insufficient clearance, obstructions and leading edges can prevent the function of the V-
TEC SRL.
To reduce the risk of a swing fall, where striking objects can cause serious injury, it is preferable to anchor
directly above the user.
The minimum fall clearance is 2.8 m (9.2 ft). Fall clearance is calculated as the vertical distance between the
working platform and the first obstacle below (such as the next platform or ground). Working limits vary
based on anchor location. Reference
If the V-TEC SRL is attached to an anchor that may deflect or deploy in a fall, such as a deadweight anchor or
anchor line, the additional deployment of that device shall be added to the minimum clearances specified in
Table 2
.
To reduce the potential for injury in a fall, the fall distance should be minimised.
EN / IRAM / NBR
EN 795* and/or CEN/TS 16415
EN 361*
EN 362*
12 kN
ANSI/OSHA
ANSI Z359.18
ANSI Z359.11
ANSI Z359.12
3600 lbs (16 kN) certified
5000 lbs (22.5 kN) non-certified
Table 2 Acceptable Anchor
V-TEC SRL
CSA
CSA Z259.13 / CSA Z259.15
CSA Z259.10
CSA Z259.12
5000 lbs (22.5 kN)
Locations.
GB
7
