EN
– Use the charger in a room only.
– The power cord must not be damaged with sharp or hot objects, open fire, it must not be
sunk into water or bent over sharp edges.
For trouble-free operation of the vacuum cleaner, please use the
tested micro-filters recommended by the producer.
II. EQUIPMENT AND ACCESSORIES (Fig. 1)
A – vacuum cleaner
A1 – ON / OFF button
A2 – LED control panel
A3 – operation signal lights and charging lights
A4 – dust container
A5 – hinged bottom
A6 – hinged bottom locking button
A7 – HEPA filter
A8 – separator
A9 – handle
A10 – battery locking button
B – battery
B1 – button Adjustment of suction power
(MIN / ECO / MAX)
B2 – suction power indicator lamps
B3 – charging connector
C – extension attachment for accessories
C1 – metal suction tube
C2 – flexible suction hose
C3 – metal suction tube with a joint
C4 – joint
C5 – joint lock
C6 – attachment locking buttons
III. VACUUM CLEANER PREPARATION
Remove all packing material, take out the vacuum cleaner and the accessories. Remove all
possible adhesion foils, stick-on labels or paper from the appliance.
VACUUM CLEANER ASSEMBLY
When assembling the vacuum cleaner, follow the procedure indicated in Fig. 2. Select
appropriate accessories (Fig. 13) depending on the required use. For disassembly, proceed
the other way round and release the locks.
CHARGING THE ACCUMULATOR
Turn the vacuum cleaner off prior to charging! Connect the adaptor to the charging
connector B3 and plug it to the mains (Fig. 3). The accumulator has to be charged at least
for 5 hours prior to the first use. After that, the standard charging time is approx.
4.5 hours.
C7 – metal telescopic tube
C8 – telescopic suction tube locking
D – floor nozzle with rotation brush
D1 – floor nozzle lock button
D2 – LEDs illuminating the space in front
of the vacuum cleaner
D3 – removable brush
D4 – brush lock
E – brush
F – long crevice nozzle
G – small direct-drive turbo brush
G1 – nozzle lock button
G2 – brush lock button
G3 – removable brush
H – adapter
I – plastic wall bracket
J – screws
K – wall plugs
L – cleaning tool
26 / 56
