3
Operation
Combining timers
The two timers can be set at the same time. Either timer can be
programmed to activate prior to the other
▶ Set the on timer and off timer.
The settings will be automatically combined.
Current time
Setting of ON timer
Setting of OFF timer
Switch-on time
Switch-off time
Table 7 Example
You can not program the on timer and off timer to operate the unit at
different temperatures or with other settings.
3.8

Other functions

3.8.1

Setting the swing function

NOTICE
If the louvre remains at the lowest position during cooling mode for an
extended period, condensate may be discharged. Adjusting the louvre
by hand may cause faults.
▶ Only use the remote control to adjust the louvre.
Automatic vertical Swing mode (up/down)
▶ Press the Swing key until the symbol
▶ To cancel the automatic vertical Swing mode: press the Swing key
again.
Cleaning position
To make cleaning easier, the louvre can be brought into a special position
(depending on product type).
▶ Press the Mode and Swing keys simultaneously for one second when
the device is switched off.
▶ To exit the cleaning position: press and hold both keys again.
3.8.2 Setting the air guide function (only AC166i... MS 4C)
▶ Press the Vane key until the desired louvre is selected.
The setting changes in the following sequence:
-1 -2 -3 -4
-0 indicates that all 4 louvres have been selected.
3.8.3

Changing over display and alarm buzzer (Mute Mode)

▶ To switch on or off the display at the indoor unit and the alarm buzzer:
press LED key.
▶ To display the current room temperature, press the LED key and hold
for 5 seconds.
▶ To display the set temperature: press and hold the LED key for
another 5 seconds.
3.8.4

Turbo cool/Turbo heat

When Turbo cool/Turbo heat is active, the indoor unit operates at
maximum power to heat or cool the room quickly.
▶ Turbo cool: switch on Cooling mode and press the Turbo key.
▶ Turbo heat: switch on heating mode and press the Turbo key.
Exiting the function:
▶ Press the Turbo key again.
14
13:00 o'clock
4.0 h
8.5 h
17:00 o'clock
21:30 o'clock
appears.
-0
3.8.5

Indirect airflow (Wind avoid me)

▶ To activate the indirect airflow: press
This function prevents a direct airflow on to persons.
The function is only available in cooling mode, dehumidification mode
and Fan Mode.
3.8.6

Key lock function

AC166i... MS 4CC
The keys of the remote control can be locked with the keylock.
▶ To switch the keylock on/off: press the Clean and Turbo keys
simultaneously for 5 seconds.
The symbol appears in the display when the keylock is active.
AC166i... MS 4C
The keys of the remote control can be locked with the keylock.
▶ To switch the keylock on/off: press the Vane and Turbo keys
simultaneously for 5 seconds.
The symbol appears in the display when the keylock is active.
3.8.7

Advanced operating functions

AC166i... MS 4CC
▶ Press the Set key.
▶ Press the Set key or ., / keys to select the function.
– = Follow Me function
– = Wireless control function
▶ Confirm selection with the OK key.
Exiting the function:
▶ Repeat the above steps.
AC166i... MS 4C
▶ Press the Set key.
▶ Press the Set key or ., / keys to select the function.
– = Self-cleaning
– = Follow Me function
– = Wireless control function
▶ Confirm selection with the OK key.
Exiting the function:
▶ Repeat the above steps.
Self-cleaning ( , AC166i... MS 4C)
The device has a self-cleaning function for the evaporator. The self-
cleaning freezes dust, mould and grease. Everything is then quickly
defrosted and dried with hot air.
Follow me function (Follow Me)
The function activates the remote control at the current location in order
to measure the temperature at 3-- minute - intervals. The indoor unit is
now controlled with reference to these measurements.
The Follow Me function is only available in cooling mode, heating mode
and automatic mode.
Wireless control function
The purpose of this function is to establish a connection via WLAN.
To connect to WLAN an IP-Gateway (optional accessory) must be
installed.
Logacool AC166i MS – 6721849826 (2023/04)
key.
