ENGLISH
the blue light is flickering,, it means the battery is not completely charged. To ensure the
maximum cleaning time, wait until the light is steady, as this will indicate the battery is
fully charged and the robot is ready to clean.
Warning
- Take the robot vacuum cleaner to the charging base if the battery is low. The robot vacuum
cleaner may not turn on if the battery is very low.
- The robot vacuum cleaner will automatically turn on when placed on the charging base.
- The robot vacuum cleaner cannot be turned off during charging.
Installing the mixed tank. Fig. 8
- Open the tank silicone cover, fill the tank with water carefully so water does not come out.
Make sure the silicone cover is properly closed to avoid water from leaking. Never immerse
the tank in water or other liquids.
- Install the mop on the mop bracket.
- To install the tank on the robot vacuum cleaner, follow the direction shown in figure 8 and
manually press the tab and push it into the correct position. You will hear a click when it is
properly fixed.
- Install the mop bracket following the direction shown in figure 8.
Recommendations:
- It is not suggested to use the scrubbing function for the first-time use.
- Do not use the mopping function if the robot vacuum cleaner is not being supervised.
- To remove the mop bracket, press the release button and pull from it outwards.
- Uninstall the mop bracket when the robot vacuum cleaner is charging or when not in use.
- Add a few drops of cleaning agent to the water if necessary, as long as it is non-corrosive.
- Using cleaning agents in excess might block water outlets.
- To achieve perfect scrubbing, it is suggested to moisten the mop before using it.
First use
- Once the robot vacuum cleaner and the charging base are installed, follow these steps
before the first cleaning.
- First, fully charge the robot vacuum cleaner. It is suggested to allow the robot to charge
overnight. When it is fully charged, it may carry out the first cleaning cycle and save the
first map. To do so, activate the Auto mode and select the Eco suction level. It is very
important to follow these instructions so that the robot vacuum cleaner recognises every
corner of your house and can carry out a complete mapping of it.
- If your house is very large and the robot vacuum cleaner runs out of battery, it will return
to the charging base, save both complete and incomplete maps, and, once charged, it will
resume cleaning where it left off until the entire surface has been mapped. The robot
vacuum cleaner is constantly mapping, so it adapts in an individualised and personalised
way to the particularities of each house while constantly improving its map.
52

3. OPERATION

Robot vacuum cleaner's buttons
Auto mode
- Press the Start/Pause button on the robot vacuum cleaner or select it in the app to make it
start cleaning automatically in Edge mode and then perform a cleaning cycle in an orderly
zigzag pattern while it also recognises which areas have been cleaned and which have not.
The robot will automatically plan the cleaning route as it is cleaning.
- If during this mode the robot is controlled manually, it will calculate the route again and
could go through previously cleaned areas. To ensure efficient cleaning, do not operate the
robot vacuum cleaner manually during automatic cleaning.
- Thanks to its Total Surface 2.0 technology, if the battery is low during the cleaning cycle,
the robot vacuum cleaner will smartly return to the charging base automatically and once
fully charged, it will resume the cleaning process from the same point.
- During cleaning, the robot vacuum cleaner will stop briefly to evaluate the area and
calculate the cleaning route (this stop will vary depending on the house conditions).
Back home mode
- Press the Back Home button on the robot vacuum cleaner or select it in the app to send
the robot vacuum cleaner to the charging base. The robot vacuum cleaner will continue
vacuuming until it reaches the charging base.
- This mode can be activated during any cleaning cycle.
- The robot vacuum cleaner will take the shortest route back to the charging base thanks to
its map memorizing and the smart back home function.
- Upon completing a cleaning cycle or when the battery is low, thanks to its TotalSurface
2.0 technology, the robot vacuum cleaner will automatically return to the charging base to
avoid running out of battery. Once the robot has recharged, it will resume cleaning from
the point it has stopped.
Note:
If there is no good access to the charging base, the robot will not be able to return to it. If this
happens, place it manually on the charging base.
Functions
Pause:
While the robot vacuum cleaner is running, press the Start/Pause button on the robot vacuum
cleaner or select it in the app to pause the cleaning process. Press the Start/Pause button on
the robot vacuum cleaner or on the app to resume the cleaning process.
ENGLISH
ETERNAL LASER VITAL
53
