ENGLISH

1. PARTS AND COMPONENTS

Fig. 1.1
1. Back home button
2. Start/Pause button
3. Laser
4. Reset
5. Bumper
6. Infrared sensors
7. Free-fall sensors
8. Charging terminals
9. Omnidirectional wheel
10. Side brushes
11. Internal battery
12. Driving wheels
13. Main brush
14. Mixed tank
Robot vacuum cleaner's accessories Fig. 1.2:
1. Charging base
2. Mixed tank
3. Side brushes
4. High-efficiency and primary filter
5. Adapter
6. Cleaning brush
7. Mop bracket
8. Mop
9. Multifunctional brush
10. Instruction manual
Charging base Fig. 2:
1. Operation light indicator
2. Signal transmission area
3. Charging connector
4. Charging terminals
Mixed tank Fig. 3:
1. High-efficiency filter cover
2. High efficiency & primary filter + sponge
50
3. Silicone cap
4. Tank lock
Please note
The graphics in this manual are schematic representations and may not exactly match the
product.

2. BEFORE USE

- This robot vacuum cleaner includes a package designed to protect it during transport. Take
the robot vacuum cleaner out of the box. Keep the original box and other elements in a safe
place, as this will help you prevent product damage when transporting it in the future. In
case the original packaging is disposed of, make sure all packaging materials are recycled
accordingly.
- Make sure all parts and components are included and in good conditions. If there is any
piece missing or not in good condition, immediately contact the Technical Support Service
of Cecotec.
Warnings
- Remove all objects around the robot vacuum cleaner such as clothing, papers, cables,
curtains, or other fragile objects which may block or slow down the operation of the robot
vacuum cleaner. Fig. 4
- If the room to be cleaned is near a balcony or stairs, a physical barrier should be placed to
prevent the robot vacuum cleaner from falling and getting damaged, thus ensuring safe
operation. Fig. 5
- Do not use the robot vacuum cleaner for liquids. Fig. 6
- Direct exposure to sunlight or great light contrasts may affect the correct operation of the
sensors. If this happens, the robot will stop operating. Move it to a new location for it to
start operating again.
- Please note that the robot vacuum cleaner's total height is 8 cm, and the sensors are on
the bottom, so it is advisable to disable all access below 8 cm to avoid damaging the laser.
Installing the robot vacuum cleaner and charging base
1. Place the charging base against a wall and leave a minimum free space of 1.5 metres at
the front and 0.5 metres on each side. Fig. 7
2. Connect the charging base to a power socket. Wind and store the remaining cord to
prevent accidents.
3. Hold down the Start/Pause button for 3 seconds.
4. When the light indicator turns on, place the robot vacuum cleaner on the charging base
and make sure the charging terminals on the robot match those of the charging base. If
