Protective precaution

The torque transducers T5 are designed in protection class IP50 to
EN 60 529. Protect the transducers against coarse dirt, dust, oil and moisture.
14

Maintenance and servicing

The torque transducer T5 are to a large extent designed to be maintenance
free. Only the sliprings and carbon brushes are subject to slight wear, which
must be monitored.
For reasons of functional safety, the carbon brush dust should be removed
from the housing of the transducer (see Tab.5.1). To do this, remove the cover
screwed on at the side and carefully remove the carbon dust or dirt present
using a fine brush and dry compressed air.
Replacement of the carbon brushes can only be carried out in the factory at
Darmstadt.
T5
Nominal (rated)
torque
[N⋅m]
10; 20; 50; 100; 200
Tab.5.1: Service life of the brushes
Please note that the service interval is shortened for increasing operating
speed!
Example:
Speed 4000 rpm
Speed 1500 rpm
A0199-4.1 de/en
Service life of brushes,
approx.
[revolutions]
8
3x10
Removal of brush dust after approx.
42 hours
Removal of brush dust after approx.
111 hours
Removal of carbon dust
after:
[revolutions]
7
1x10
25
