SYSTEM ELEMENTS

INNOBUS PRO6 MAIN CONTROL BOARD (AZCE6IBPRO6)

Electronic board that controls the system through wired and wireless devices. Wall mounted.
Functionalities:
·
Control and management of the thermostats (up to 6 zones).
·
Power outlets for motorized elements.
·
Remote zone on/off module (up to 6 zones).
·
Relay outlet configurable as CMV (Controlled Mechanical Ventilation) or
boiler.
·
Control gateway management.
·
Communication with units of integral control of the installation.
· Communications with other external control systems through integration bus.

Technical specs

Power supply and consumption
Type of power supply
Stand-by consumption
Maximum consumption
Module over-current protection
Communications via radio
Communications protocol
Radiation power
Maximum distance in open space
Operating temperatures
Mechanical aspects
Protection class
Dimensions (WxHxD)
Vac
V max 110 / 230 V
250 mA
I max
Frequency 60/50 Hz
400 mW
25 W
250 mA
Airzone
Frequency 868 MHz
5 dBm
40 m
Storage -20 ... 70 ºC
Operation 0 ... 50ºC
IP 20
Weight 616 g
195x180x55,5 mm
Type
Licence
Application
Control accuracy (K)
Communications protocol
Maximum number of outputs per
Airzone Central V1.3
215562
Variable air volume system (without h/c coil)
Heating
0.3
Airzone connection bus
Nº of ports 3
Shielded twisted pair 2 x 0,22 + 2x0,5 mm
V max 12 V
Automation bus
Nº of ports 1
Shielded twisted pair 2 x 0,22 + 2x0,5 mm
MODBUS RS-485
Par – 19200 bps
Actuator outputs
Nº of outputs 6
2
damper
Vmax ± 12 V
Imax 150 mA
Relay outputs
Nº of relays 2
V max 24 / 48 V
I max I max
Cooling
0.3
