Technical Data

Dimensions: L x W x H: 238 x 195 x 73,50 mm
Environmental conditions:
Storage temperature:
Ambient temperature:
Humidity:
Minimum temperature stability of the connecting li-
nes:
Heating system, lighting circuits, stove and bench lines
are heat-resistant to at least 150°C .
Maximum lengths of lines:
stove sensor:
bench sensor:
Control:
Switching voltage / three-phase 3N:
Frequency:
Switching capacity / heating AC 1:
Switched current each phase /
heating AC 1:
Switching capacity /
steam generator AC 1:
Switching capacity /
steam generator AC 1:
Nominal voltage:
Min. / max. pick-up capacity:
Degree of protection (splash-proof):
Connection to the main circuit as permanent wiring
(non-detachable connection).
Steam generation:
On/ Off time:
Min. / max. inrush impulse:
Light:
AC1 switched current:
WE DO IT FIRST.
Instructions for installation and use
-25°C to + 70°C
-10°C to + 40°C
max. 95 %
3 m
3 m
400 V
50 Hz
3 x 3 kW
13 A
3 kW
13 A
230 V
4,3 / 6,3 VA
IP X4
approx. 200 s
approx. 10 / 200 s
1A
Thermal safety:
Stove sensor with overtemperature protector,
shutdown temperature 139°C.
Automatic shutdown after, at the maximum of 6 hours
(depending on the factory setting).
Dual sensor system with temperature controls via stove
and bench respectively.
Optional sauna door safety-monitor when the desired
time has been set:
• Without heating operation:
- The desired time set will be cancelled on opening
of the sauna door.
• With heating operation at temperatures below
40°C:
- The heating will be shut down.
- Restarting the control is necessary.
• With heating operation at temperatures above
40°C:
- The heater will shut down, if the sauna door remains
opened for more than 5 seconds.
- Heating continues on closing the sauna door.
Range of adjustment:
Sauna operation:
Steam operation:
Steam generator:
Selected start-time:
Min. of selected start-time:
Max.of selected start-time:
Duration of heating:
* If used in apartment buildings, hotels, or similar buil-
dings, the operational timeframe has to be limited to
12 hours.
Edition: 07-2012
• 12 •
P. 12/14
40-125 degrees Celsius
above the stove.
40-65 degrees Celsius
at the bench.
00 - 100 % steam output
in 15 minute increments
15 minutes
23 hours 45 min.
Automatic shutdown
after 6 hours*.
Ident-No. ,1511044
