Master-Slave Mode; C) Sound-To-Light Mode - Renkforce DL-LED107S Bedienungsanleitung

Symbol Option
Addr 001-507
VEr db20
Led on
oFF
SLNd NASt
SLAv
ShNd SoUn
CoLo
SPee
dISP dISP
dSIP
ChNd 6Ch
3Ch
b) Master-Slave Mode
• Set the menu NASt to define the device as a master (control via the installed controller).
• Set the menu SLAv to define the device as a slave (control via the controller of the connected master
device).
If the device is to be operated as a single device (stand alone), it must be defined as a master
device.
Only one device in a master-slave-chain must be defined as master device. All other devices
must be defined as slave devices.

c) Sound-to-Light Mode

• Set SoUn in the menu to operate the device in sound-to-light operation.
• The effect light is controlled via an installed microphone in time with the music.
Function
Setting the DMX starting address
Display of the software version
Display permanently on
Display switches on only after pushing a button
Operation as a master device
Operation as a slave device
Sound-to-light mode
Automatic operation with colour effects
Speed setting for automatic operation
Display aligned normally
Display alignment turned by 180°
6-channel DMX operation
3-channel DMX operation
25
