Mounting the Filter Unit on the Trolley with Flexsafe

STR Lifting Device
Person- 2 people (operators)
nel:
Material: Lifting Gear Maxicaps
2
Fig. 9: Lifting Gear
Pos. Name Description
1 Hook Attaches the Lifting Gear to the filter unit attach-
ment points.
2 Setting Used to adjust to the width of the filter unit.
range
Requirements
— The handles are mounted on the filter unit.
— The trolley is positioned so that the system rail with air filter holder is
aligned with the rear.
— The parking brakes are activated.
WARNING
Risk of injury if system parts fall!
Observe the proper procedure when mounting.
t
WARNING
Risk of injury if the Flexsafe
The Flexsafe STR Lifting Device may tip over if the maximum load-bearing
®
capacity is exceeded. People may be injured as a result.
Observe the maximum load-bearing capacity of the Flexsafe
t
ing Device (see load chart for Flexsafe
Process Preparation
MR and Flexsafe
® ®
1 1
STR Lifting Device tips over!
®
STR Lifting Device).
®
Maxicaps MR Operating Instructions
®
®
STR Lifting Device
STR Lift-
®
