System Description
14 Maxicaps MR Operating Instructions
®
3.5

Swivel Function

The swivel function helps you move the filter unit into an inclined position.
The swivel function can be used when venting and emptying the filter unit.
3
Fig. 5: Swivel function settings
Pos. Name
1 Venting position
2 Filtration position
3 Emptying position
Description
The filter unit is swiveled approx. 30˚ to
the left.
The filter unit is aligned vertically.
The filter unit is swiveled approx. 30˚ to
the right.
1
2
