Valve Actuators

The three valve actuators are used to open and close the valves in the filter
unit. The valve actuators must be mounted on the filter unit.
1
3
Fig. 6: Valve actuators
Pos. Name
1 Valve actuator
[open]
2 Valve actuator
[close]
3 Valve actuator
lock
System Description
Description
The valve actuator lever points towards
[open]. The filter unit valve is opened.
The valve actuator lever points towards
[close]. The filter unit valve is closed.
Fixes the valve actuator in place.
