Gebrauchsanweisung – Hercules Small Instructions for Use – Hercules Small
Shoulder pads
The shoulder pads provide support in the shoulder area.
The two elastic straps are pulled over the side impact protection. One band is placed
on the back and one band on the side.
Thorax pelotte pads, rigid / swivelling
The thorax pads provide support for the upper body that can be individually adjusted
to the user in height and width. The two pads are adjusted independently of each
other, thus an optimal adaptation to the user is possible.
The thorax pads are mounted in the two slots of the back plate. (Fig. 44)
To mount the pads, first loosen the back padding at the top of the back plate. (Fig.
15) Mount the thorax pelotte pads on the front of the back plate. (Fig. 45) Insert the
screws through the back plate and the mounting bracket from behind. Fit the nuts
from the front. Tighten the nuts firmly. Now the back cushion can be pulled over the
top of the back plate again
Armrests
The armrests provide a support surface for each arm of the user.
The armrests are mounted in the two slots in the back plate. (Fig. 46). Insert the
screws through the back plate and the mounting bracket from behind. The nuts are
mounted from the front. The armrests can be adjusted in height. Tighten the nuts
firmly.
For easy positioning of the user, the armrests can be swivelled upwards. (Fig. 47)
When the user is safely positioned, the armrests are swung down again.

Forearm rest (only in combination with the armrests)

The forearm support provides continuous, large-area support for the forearms
First mount the armrests. Now position the lower armrest on the armrests. (Fig. 48).
Connect the lower armrest to the armrest on each side using the plug-in fastener. (Fig.
49) The position of the lower armrest can now be adjusted using the lower straps.
(Fig. 50) Then pull the elastic straps at the bottom of the front end of the lower arm-
rest over the armrests on both sides.
